OVERVIEW

    • 8-Channel Live View and 4K HDMI Video Output
    • 8× 10/100 Mbps PoE+ Ports with 93 W PoE Budget△
    • 4-ch @ 4MP/ 8-ch @ 2MP Decoding Capability
    • 8-Channel Synchronous Playback†
    • 80 Mbps Incoming Bandwidth and 60 Mbps Outgoing Bandwidth
    • 2× SATA Interfaces and 1 Up to 16 TB*
    • H.265+ Compression Technology
    • HDMI and VGA Simultaneous Output
    • Remote Monitoring

    SPECIFICATIONS

    VIDEO AND AUDIO
    IP Video Input 8-Channel
    Incoming Bandwidth 80 Mbps
    Outgoing Bandwidth 60 Mbps
    HDMI Output Resolution 1 Channel, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
    VGA Output Resolution 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz
    Video Output Mode HDMI/VGA Simultaneous Output
    Multi-View Display 1/4/6/8
    DECODING
    Audio Compression G.711A/G.711U/G.726
    Video Compression H.265+/H.265/ H.264+/H.264
    Record Resolution 8MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF
    Synchronous Playback 8-Channel†
    Capability • 25fps:
    2-ch @ 8MP, 4-ch @ 4MP, 8-ch @ 2MP

    • 30fps:
    4-ch @ 3MP, 2-ch @ 5MP
    RECORD MANAGEMENT
    Record Mode • Manual Recording
    • Scheduling Recording
    • Motion Detection Recording
    Playback Mode • Instant Playback
    • Regular Playback
    • Tag Playback
    • Event Playback
    Backup Mode • Regular Backup
    • Video Clip Backup
    Playback Function • Play
    • Pause
    • Stop
    • Fast Forward
    • Fast Backward
    • Play By Frame
    • Full Screen
    • Video Clip
    • Export Clip
    • Digital Zoom
    • Lock Recording
    • Audio On/Off
    NETWORK
    Protocol UPnP (Plug and Play), NTP (Network Timing)
    Mobile Phone Access Android, iOS
    Web Browser Chrome (57+), Firefox (52+), Edge (91+)
    Interoperability ONVIF, CGI
    EXTERNAL INTERFACE
    Network Interface 1, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
    USB Interface 1 Front USB 2.0 Port, 1 Rear USB 2.0 Port
    Audio Interface 1, Audio In; 1, Audio Out
    Alarm In/Out N/A
    Serial Interface N/A
    Power 1× DC Jack
    Reset Button 1
    Speaker N/A
    eSATA 1
    HDMI 1
    VGA 1
    HARD DISK
    SATA 2 SATA Interfaces
    Capacity Up to 16 TB Capacity for Each HDD*
    POE
    Standard 802.3at/af Compliant
    Interface 1-8, RJ-45 10/100 Mbps Self-Adaptive Ethernet Interface
    PoE Budget 93 W△ Available for All PoE+ Ports, 30 W Max per Port
    ALARM
    General Alarm • Motion Detection
    • Video Tampering
    • Line-Crossing Detection
    • Intrusion Detection
    • Region Entering Detection
    • Region Exiting Detection
    • Object Abandoned/Removal Detection
    • Vehicle Detection
    • Human Detection
    • Smart Frame
    Anomaly Alarm • Video Loss
    • Offline and IP Conflict
    • Disk Exception
    • Login Exception
    • Fan Exception
    Alarm Linkage • Recording
    • White Light Alarm
    • Buzzer
    • Log
    • Audible Alarm
    GENERAL
    Storage Temperature -40–70 °C
    Storage Humidity 10%~90% RH Non-Condensing
    Package Contents • VIGI Network Video Recorder
    • Power Adapter
    • Power Cables
    • HDD Power Cables
    • HDD Data Cables
    • Mounting Accessories
    • Mouse
    • Quick Installation Guide
    Working Temperature • NVR: -10–55 °C
    • Power Adapter: 0–40 °C
    Working Humidity 10%~90% RH Non-Condensing
    Dimensions( W X D X H ) 330 × 285 × 45 mm
    Net Weight 2.1 Kg
    Gross Weight 4.1 Kg
    Power Supply 53.5V DC/2.43A
    Power Consumption • 4.9 W△ (Without Disk)
    • 35 W△ (With Disk)
    Certifications CE, EAC, UKCA, RCM, Triman, BSMI, VCCI, FCC, IC, HDMI

    DOWNLOADS

    Datasheet of VIGI NVR2008H-8MP
